paper slitting machine of paper processing machine

1.0 Sets
MOQ
paper slitting machine of paper processing machine
Features Gallery Product Description Request A Quote
Features
Specifications
Applicable Industries: Home Use, Retail, Printing Shops, Advertising Company, Paper Industry
Showroom Location: Egypt, Canada, Turkey, United Kingdom, United States, France, Germany, Viet Nam, Philippines, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Spain, Thailand, Kenya, Argentina, South Korea, Chile, Algeria, South Africa, Ukraine, Japan
Condition: New
Type: Slitting Rewinding
Computerized: Yes
Voltage: 380V
Weight: 2000 Kg
Warranty: 1 Year
Production Capacity: 7000 Sheets/h
Key Selling Points: High Productivity
Max. Workable Width: 1200mm
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Marketing Type: Hot Product 2019
Warranty Of Core Components: 1 Year
Core Components: Motor, Other, Gear, Engine, PLC
PLC Brand: Schneider, Omron, Siemens
Product Name: Die Cutting Machine
Function: Cardboard Automatic Die-cutting Machine
Name: Paper Folding Machine China
Application: Industrial Paper Cutting Machine
Keyword: Die Cutting Corrugated Board
Model: 1325/1625/1825/2125
Machine Type: Small Paper Making Machine
Power: 3KW
Basic Infomation
Model Number: 1325/1625/1825/2125
Payment & Shipping Terms
Packaging Details: Wooden Case or Customized Package.
Supply Ability: 50 Set/Sets per Year
Product Description
Specification
RIEF
(1) The machine is specialized in rewinding jumbo paper roll into small rolls, including 3 specifications: paper core, non-core,
stiffener. It is widely used for gift paper, advertisement paper, wall paper and so on.
(2) High precision to fix the length, rewinding neatly, easy operation, beautiful appearance, running stable
MATERIALS FOR CONVERTING
Gift wrap paper
Film
Posters
Table-covers
Household paper
Packaging paper (kraft paper)
Wall paper
Self-adhesive film
Technical parameter
Control system
Max width mother roll
1600mm
PLC Controller
Delta(Taiwan)
Min-width finish roll
35mm
Main-machine interface
Thinget
Max-diameter mother roll
1500mm
Tension sensor
Hz100kg
Max-diameter finish roll
1300mm
Actuator
CHNT
Speed of Slitting
0-300m/min
Signal component
Omron
Slitting capability
60-700gsm
Pneumatic component
Airtac
Rewinding way
By pneumatic
Program edition
JS-RSV2.0
Slitting knife
21set
Inverter
YASKAWA 15KW
Paper giving way
By liquid compression
Length sensor
Have
speed of adjust and control
Inverter
outfit assemble
Power input
380V 3 phase 4 lines
Loading material
Hydraulic
Size (mm) L*W*H
Unloading material
Manual
Unwinding machine
3700*1300 *1000mm
Automatic aim edge
Hydraulic edge correcting
Rewinding machine
2250*2300*1000mm
Count meter
Have
Up-knife specification
4*105*70mm
Tension adjust
magnetic powder brake
Down-knife specification
4*105*70mm
rewind single airshaft
Total weight
5000kg
Slitting by clipper,
Drive system
Sensor for tension control system
Mainframe power
11KW
Enclosed component
Mainframe wheeling speed
1400r/min
Air compressor
no
Liquid compression motor
1.5kw
Useful tool
have
Company Profile
We are QINGDAO JIERUIXIN MACHINERY AND TECHNOLOGY CO.,LTD. which company is mainly working on paper coating machine, paper making machine and related technology. Through more than 20 years effort, Besides the machine self, we have our own chemist and prefer to supply chemical, formulation, technology and other suggestion to customers. Then our formulation will match our machines, and get the best quality paper for them. Now Our company had been one of the famous paper coating machine manufacturer in China and our coating machine and technology had been exported to Egypt, Mexico, Australia, India and etc. Our Services ( We can provide turnkey works) 1.Reasonable suggestions for selection of equipment. 2.Provide detailed description and assembly drawing to make you more aware of the device ability to work. 3.Engineers on site equipment installation and commissioning. 4.Provide training for your employees. 5.Professional technical guidance and technical support during your production, make sure the device's work properly and production. 6.Equipment upgrade and remould. 7.We will testing installation machine in the factory workshop , to ensure safety and quality. 8.Supply chemical ,formulation ,technology and other suggestion to customers. QINGDAO JIERUIXIN MACHINERY AND TECHNOLOGY CO.,LTD. the real person hood, steadfast work management concept, we warmly welcome all friends to visit.
FAQ
1. who are we?
We are based in Shandong Province, China, start from 2017,sell to North America(36.00%),Mid East(18.00%),Eastern Asia(16.00%),South America(10.00%),Eastern Europe(8.00%),Africa(8.00%),Southern Europe(4.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
paper coating machine,Paper making machine,paper coating machine parts,thermal and NCR paper coating chemical,Coated paper coating production line

4. why should you buy from us not from other suppliers?
Our company is specially working on paper coating industry and coating technology .Now our paper coating machine have exported to Egypt,Mexico,Austrilia and other country .Meanwhile our chemical engineer have more than 20 years paper coating experience

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF;
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish
